| 起源の場所: | 河南省、中国 |
| ブランド名: | WNRLN |
| 証明: | ISO 9001:2015 |
| モデル番号: | 1A1-200-D126 |
| 最小注文数量: | 5個 |
|---|---|
| 価格: | USD 80-180 / Piece |
| パッケージの詳細: | 保護フォームインサート付きの WNRLN ブランドボックス、輸出グレードの段ボール箱 |
| 受渡し時間: | 在庫に3〜5営業日、生産に15〜20日 |
| 支払条件: | T/T、L/C、ペイパル、ウェスタンユニオン |
| 供給の能力: | 1 か月あたり 10,000 個 |
| 輪の形状: | 1A1(フラット) | 直径: | 200mm |
|---|---|---|---|
| グリットサイズ: | D126 | 債券の種類: | 電子化されたニッケル |
| アブラシブ材料: | 総合的なダイヤモンド | 適用材料: | アルミナ（Al₂O₃）、ジルコニア（ZrO₂）、窒化ケイ素（Si₃N₄）、炭化ケイ素（SiC） |
| 硬度: | モス10 | 最大回転数: | 3500rpm |
| オーバーホール: | 32mm | ||
| ハイライト: | electroplated diamond grinding wheel 200mm,diamond surface wheel for ceramic processing,D126 grinding wheel for alumina zirconia |
||
The 1A1 Electroplated Diamond Grinding Wheel 200mm D126 is a premium abrasive solution engineered for precision machining of hard brittle ceramic materials. Leveraging the exceptional hardness of synthetic diamond (Mohs 10), this grinding wheel maintains stable cutting performance across the most demanding industrial applications.
Diamond ranks at the highest level of the Mohs hardness scale among all natural and synthetic materials. This unmatched hardness enables our electroplated diamond grinding wheel to effectively process the full range of advanced technical ceramics:
| Ceramic Material | Key Characteristics | Processing Performance |
|---|---|---|
| Alumina (Al₂O₃) | High compressive strength, excellent electrical insulation | Clean, precise grinding with minimal micro-cracking |
| Zirconia (ZrO₂) | Transformation-toughened, superior fracture resistance | Stable cutting force maintained throughout entire operation |
| Silicon Nitride (Si₃N₄) | High strength at elevated temperatures, thermal shock resistant | Consistent performance without thermal degradation |
| Silicon Carbide (SiC) | Extreme hardness (second only to diamond), high thermal conductivity | Sustained abrasive sharpness and long service life |
Every grinding wheel undergoes rigorous quality control including dimensional inspection, grit distribution analysis, and rotational balance testing. Manufactured under ISO 9001:2015 certified processes, our electroplated diamond wheels deliver consistent, reliable performance batch after batch.
Contact our technical sales team today to discuss your specific ceramic grinding requirements. We offer custom grit sizes, dimensions, and specifications to meet your exact application needs.
